Klaxon Diesel

Klaxon Diesel Water Pumps

Friday, June 6th, 2014

Pump model	KDWP20C	KDWP30C	KDWP40C
Suction Dia	50mm	80mm	100mm
Discharge port Dia	50mm	80mm	100mm
Max. capacity	600L/min(36m³/hr)	1000L/min(60m³/hr)	1600L/min(96m³/hr)
Cont. capacity	366L/min(22m³/hr)	600L/min(36m³/hr)	1066L/min(64m³/hr)
Max. head	26m	25m	31m
Cont. head	15m	13m	16m
Self-priming time	80s/4m	120s/4m	180s/4m
Max. suction head	8m	8m	8m
Engine model	DE170FA	DE178FA	DE186FA
Engine type	Air cooled single cylinder 4-stroke direct injection Diesel Engine
Displacement	219cc	306cc	418cc
Starting system	Recoil
Engine speed	3600rpm
Engine power	4.0HP	6.0HP	10.0HP
Fuel tank capacity	2.5L	3.5L	5.5L
Net weight	38kg	48kg	67kg
DIM (LxWxH)	480x450x480mm	560x450x515mm	640x490x595mm
–
Options
Wheels and handle
12,5L large fuel tank
Electric starter and battery

If you are interested in our Diesel Generators please send a request via the Contact Form

Tags: Diesel Water Pumps
Posted in Diesel Water Pumps | Comments Off on Klaxon Diesel Water Pumps

2.5-6.0kW Diesel Generators

Tuesday, May 13th, 2014

Generator_KT2500E	Generator_KT4000E	Generator_KT6000SE
Model KT2500E KT4000E KT6000E Rated frequency (Hz) 50 / 60 50 / 60 50 / 60 Rated output (kVA) 2.0 / 2.2 2.8 / 3.0 5.0 / 5.5 Max. output (kVA) 2.3 / 2.5 3.0 / 3.3 5.5 / 6.0 Rated voltage (V) 115-230 / 120-240 115-230 / 220 115-230 / 120-240 Rated current (A) 17.4/8.7: 18.3/9.2 24.34-12.17 /13.64 43.5-21.7 / 45.8-22.5 Rated speed (r/pm) 3000 / 3600 3000 / 3600 3000 / 3600 Phase NO Single phase Single phase Single phase Power factor (cosφ) 1 1 1 Insulation grade F F F Pole number 2 2 2 Panel Type General panel General panel General panel Voltage (V) 115-230 /120-240 115-230 / 220 115-230 / 120-240 Receptacle Two receptacles Two receptacles Two receptacles DC12V output – – – Dimension: LxWxH (mm) 670x490x550 710x490x580 950x550x750 Dry weight (kg) 57 75 148 Noise Level (7M) db (A) 79 79 79 Structure type Open frame Open frame Soundproof type Engine Model 170F 178F 186FA Engine type Single-cylinder, four stroke, air-cooled Cylinder No, bore/stroke (mm) 1-70×57 1-78×57 1-86×72 Diplacement (cc) 219 306 418 Rated power [kW(Hp)/(r/min)] 2.5/3000; 2.8/3600 3.68/3000; 4.0/3600 5.7/3000; 6.3/3600 Compression ratio 20:1 20:1 19:1 Rated rotation speed 3000 / 3600 3000 / 3600 3000 / 3600 Cooling system Air cooled Air cooled Air cooled Lubrication system pressure splashed pressure splashed pressure splashed Starting system Recoil or Electric Recoil or Electric Electric Starter Fuel type 0#(summer) -10#(winter) -20#(chillness) Diesel Fuel tank capacity (L) 12 12 16 Continuos running time (hr) 15.5 16 8 Place of origin China  If you are interested in our Diesel Generators please send a request via the Contact Form

Tags: Diesel Generators
Posted in Diesel Generators | Comments Off on 2.5-6.0kW Diesel Generators

12kW Diesel Generator

Sunday, April 13th, 2014

Generator_KT12000E

Model KT12000E Generator Set Power Prime: 12kW (15kVA) Stand-By: 15kW (19kVA) Rated Voltage / Frequency 400/230V, 50Hz, 3-phase 1500rpm 60Hz Dimension of open type (mm) 1550x650x1050 Dimension silent type (mm) 1800x850x1050 Engine Model 2100DS Fuel Consumption (g/kW/h) 245 Intake Method Spomtameously aspirated Crankshaft Rotation Direction Counte Clockwise (Face to output end) Rated Speed 1500 r/pm Rated Power 15kW Governor Mechanical Cooling Way Closed water cooling Alternator Data Power Factors 0.8 lag, 3-phase & 4-line “Y” type connection Rated Power (kW)(kVA) 612 (15) Rated Current 21.7 Excitation Brushless excitation Voltage Regulation A.V.R. Place of Origin China Starting Type Electric starter  If you are interested in our Diesel Generators please send a request via the Contact Form

Tags: Diesel Generators
Posted in Diesel Generators | Comments Off on 12kW Diesel Generator
